Specifications:
1. 主體材料Body Material: Black Glass-Fiber Nylon 66.94V0
2. 電氣參數Operating data: 15A, AC250V/AC250V
3. 接觸電阻Contact Resistance:< 5mΩ
4. 絕緣電阻Insulation resistance: >100 MΩ
/500Vdc
5. 耐壓Dielectric strength: 2000 VAC/1 minute
6.
用于裝配板:裝配板厚度0.8-2.5mm
7. 標準:IEC320 C8
8. Safety Approvals(安全認證):
(尺寸及相關(guān)認證等技術(shù)參數務(wù)請確認為準)
